Product Detail

AD1000 EN-3R SCH System with Pictograms & Inductive Loop & with Surface Mounting Evacuation & Fire Fighting Including Primary/Secondary LED Indicators (Car Speaker without faceplate)

  • Part Number: AD1000 EN-3R SCH + PIC + Loop No FP + SM Evac FF
Add to Cart

-   Classic Windcrest Autodialler, has been serving the industry for over 30 years

-   EN 81-28 Compliant

-   EN 81-72 Compliant

-   BS9999 Compliant

-   Surface Mounting Combined Evacuation & Fire Fighting Intercom System with Primary/Secondary LED indicators Included

-   Main Unit designed to be Mounted on Top of the Car, Top of Car Speaker built-in to the main Unit

-   Built-in Pictograms, Car Speaker without faceplate

-   Built-in Inductive Loop

-   Includes Lift Car Speaker & Lift Pit Speaker

-   Remote Programmable

-   In Evacuation Mode - Facility to have intercom from the Evacuation/Fire Fighting Master Panel to all the Landing & Lift Car.

-   In Fire Fighting Mode - Facility to have intercom from the Evacuation/Fire Fighting Master Panel to Lift Car & Motor Room Speaker.

*Specify the total number of openings in the Lift. i.e. no. of entrances,  Floor Markings. e.g. G, 1, 2, 3, Main Exit Floor - e.g. Ground Floor and any requirements or customisation, e.g. for duplex or two masters etc, in the Notes section of the basket.
