2WAD EN-4 System with Pictograms & Inductive loop plus with Flush Mounting Evacuation & Fire Fighting without Primary/ Secondary Indicators


  • Part Number: 2WAD EN-4 + PIC + LOOP + FM EVAC FF No LEDs
Add to Cart

-   Autodialler System Operates on 2 Wire bus

-   Built-in Keypad & Display for Programming & Diagnosis

-   EN 81-28 Compliant

-   EN 81-72 Compliant

-   BS9999 Compliant

-   Car Speaker with built-in Pictograms

-   Inductive Loop Included

-   Flush Mounting Combined Evacuation & Fire Fighting Intercom System without Primary/Secondary LED indicators Included

-   Remote Programmable

-   Intercom facility between any two outstations in the system. i.e.  Top of Car to Motor Car/Pit or Pit to Car/Top.

-   In Evacuation Mode - Facility to have intercom from the Evacuation/Fire Fighting Master Panel to all the Landing & Lift Car. Motor Room can be added too on request.

-   In Fire Fighting Mode - Facility to have intercom from the Evacuation/Fire Fighting Master Panel to Lift Car & Motor Room Speaker

-   Telephone Line detection

-   Includes Lift Car, Top of Car, Lift Pit Speaker & Main Unit

*Specify the total number of openings in the Lift. i.e. no. of entrances,  Floor Markings. e.g. G, 1, 2, 3, Main Exit Floor - e.g. Ground Floor and any requirements or customisation, e.g. for duplex or two masters etc, in the Notes section of the basket.
