Product Detail

2WAD EN-3 System plus Pictograms with Flush Mounting Evacuation Intercom (Car Speaker without faceplate)

  • Part Number: 2WAD EN-3 + PIC No FP + FM Evac
Add to Cart

-   Autodialler System Operates on 2 Wire bus

-  Built-in Keypad & Display for Programming & Diagnosis

-  EN 81-28 Compliant

-  BS9999 Compliant

- Car Speaker with built-in Pictograms without faceplate

-  Flush Mounting Evacuation Intercom System Included

-  Remote Programmable

-  Intercom facility between any two outstations in the system. i.e. Top of Car to Motor Car/Pit or Pit to Car/Top.

-  Facility to have intercom from the Evacuation Master Panel to all the Landing & Lift Car. Motor Room can be added too on request.

-  Telephone Line detection

-  Includes Lift Car, Top of Car, Lift Pit Speaker& Main Unit. Motor Room Speaker is NOT included.

*Specify the total number of openings in the Lift. i.e. no. of entrances,  Floor Markings. e.g. G, 1, 2, 3, Main Exit Floor - e.g. Ground Floor and any requirements or customisation, e.g. for duplex or two masters etc, in the Notes section of the basket.
